Automatic Side Grinding Machine
Model: FL 1000 A
|
Automatic Side Grinding Machine FL 1000 A
This machine is pecially configured for the side grinding of tooth flanks on reamer cutting
edges of special saw blades with automatic feed.The feed rate can be stepessly adjusted in
the forward and reverse direction by means of 2 speed controlling valves.
| Weight: | 230 kg |
| Dimensions: | 900 mm wide |
| 1100 mm deep |
| 1550 mm high |
Cooling water tank capacity appr. 63 litres.
Delevery output of the cooling water pump appr. 20 litres/min.
Grinding wheel dia. 100 or 125 mm.
Grinding wheel speed via grinding spindle 4700 rpm,
2 speeds possible
Poly-V belt drive, 6 grooves. |
| Elecrical data |
|
| Drive motor: | 1,1 kW with switch for clockwise/anticlock |
| wise running 2800 N at two speeeds 1400 and 2800. |
| For USA, the pulleys have a different diameter. |
| Coolant pump: | 0,12 kW |
| Operating voltage: | 230/400 Volts, 50 cycles |
| 230/400 Volts, 60 cycles |
| Colour: | Green hammertone finish, malchite green.
Other colour shades possible on request | |
|
|
|
|
|
